CARACTERÍSTICAS DE HARDWARE Estándares y Protocolos IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, http, DDNS Interface 1 Fixed Ethernet WAN Port 1 Fixed Ethernet LAN Port 3 Changeable Ethernet WAN/LAN Ports Medios de Red 10BASE-T: UTP category 3, 4, 5 cable (Max 100m), 100BASE-TX: UTP category 5, 5e cable (Max 100m) Botón Reset Button Fuente de Alimentación Internal Universal Power Supply AC100-240V~50/60Hz input Flash 4MB DRAM 64MB LED PWR, SYS, WAN, LAN, WAN/LAN Dimensiones (W X D X H) 8.2*5.0*1.0in. (209*126*26mm) RENDIMIENTO Sesiones Concurrentes 10000 FUNCIONES BÁSICAS WAN Connection Type Static/Dynamic IP, PPPoE, PPTP, L2TP, Dual Access, Bigpond Cable DHCP DHCP Server/Client, DHCP Address Reservation MAC Clone Modify WAN/LAN MAC Address Switch Setting Port Mirror, Rate Control, Port Configuration, Port VLAN FUNCIONES AVANZADAS ACL IP/MAC/URL/WEB Filtering IGMP IGMP Proxy/IGMP Snooping Forwarding Virtual Server, Port Triggering, DMZ Load Balance Policy Routing, Link Backup Routing Static Routing Security FTP/SIP/PPTP/IPsec/H.323 ALG, DoS Defence, Ping of Death, IP/MAC Binding Traffic Control Bandwidth Control, Session Limit ADMINISTRACIÓN Service PPPoE Server, E-Bulletin, Dynamic DNS, UPnP Maintenance Time Setting, Daylight Saving Time, SNMP, Diagnostics, Firmware Upgrade, Factory Defaults/Reboot, Backup/Restore, System Log, Remote Management, Statistics
